BOBST
SP 102 BMA

available now, workshop refurbished, ready to test

  • Ref

    B.0282

  • Manufacturer

    BOBST

  • Model/Typ

    SP 102 BMA

  • Year of construction

    1990

  • Format

    72x102 cm

  • Configuration

    • ELEVATED MACHINE Machine elevated 415 mm, included elevation of the steps • Step • Centerline for job quick change • Electronic device for sheet travel control • Air conditioning for the electrical cabinet • Gripper bars • Bobst-electronic for managing the machine • Motore principale con variatore di frequenza • Pianale porta-pila con leva per la correzione laterale manuale della pila durante la produzione • NON-STOP FEEDER MANUAL DEVICE • Adjustable lateral blowers with Centerline references • Suction unit with multiple adjusting • Safety system for lowering the pile try • Introduction table covered by antistatic steel stainless plate • Sheet synchronization adjustable during the machine is running for adapting feeder cycle to platin cycle • Feed belt slow-down device Ensures smooth arrival of sheets against front lays • 4 front lays, adjustable in pairs with front register control • Pull-lay operator side (OS) adjustable according to Centerline, with sheet control • "Double sheet "detector • Upper frame with manual lifting device • Sheet-hold down device (guiding the sheets to front lays) • Upper transport equipment for paper, paperboard and corrugated board • Transport belts. With lateral guidance • Heated upper platen with 16 heating zones • Grippers re-opening device • Equipment centering and locking • Locking of the chase against the upper beam • Measurement of the die-cutting force using an electronic probe • Steel material print supporting plate • Compensating plate, thickness 3 mm (E-52). Compensation plate, 3 mm thick (E-52). It is used as a cutting plate for die cutting and as a compensation plate together with the 2.3 mm thick printing plate for printing and embossing • Honeycomb frame (E-6) Includes a series of cliché fixing accessories. To specify: height of the clichés of 6.35 or 7 mm • Compensating plate, thickness 2,3 mm (E-62) • 1 HONEYCOMB FRAME. It includes a series of accessories for fixing the clichés. 1 unit with the basic machine • Pile tray • Braking Brush • Pneumatically controlled adjustable front joggers • AUTOMATIC NON-STOP BELT. The belt automatically enters on delivery when the pile of sheets is complete. Facilitates the use of non-stop by eliminating the manipulation of the grid. This mat replaces the Non-stop grille (Standard) • Pneumatically controlled adjustable lateral and front joggers with Centerline marks • Removable tape feeding module. Including a trolley equipped with: 3 shafts for adjusting the advancement of the belts driven by motors • 2 telescopic reel holder guides • 2 reel-holder boards • 2 additional roll-holder axles for preparation outside the machine • 3 sets of 8 roll holders with 3° combined spindles consisting of: 1 set of narrow rolls; 1 set of medium coils; 1 set of reels with brake • 30 wide drive rollers, 38 mm wide • 1 automatic device for putting the platen "on and off" pressure • 1 Margin line. Facilitates the positioning of clichés • 1 device for manual tapes introduction (mounted on the autoplaten) • 1 blower with nozzles to detach the belts after printing (mounted on the platen) • 1 blower inside the platen to stabilize the sheets of paper before printing or die-cutting (mounted on the platen) • 1 belts guide on the upper post (mounted on the platen • 1 belt tension shaft driven by a motor with air cooling device (mounted on the platen) • 1 bands break control system with 16 photo-electric cells with lateral adjustment for immediate machine stop in case of band breakage • 1 lateral evacuation device for metal band with rotary brushes at variable speed depending on the advancement of the belts (mounted on the platen) • 1 longitudinal belts cutting device (mounted on the platen) • Operator safety devices • Gripper Bar Chain Slip Clutch • Handling of the diecutting equipment • Emergency Stops • Photoelectric cell safety barriers located at the feeder and at the delivery

  • Delivery date

    February 2025

Ask for an offer
